Passive RFID FPC Tag
🔹 Overview
The Passive RFID FPC Tag is a miniature, flexible RFID transponder integrating a high-performance chip, etched copper antenna, and polyimide (PI) film substrate. Designed for space-limited and curved-surface mounting, it delivers consistent RFID performance with ultra-slim profiles (down to 0.13mm) and excellent flexibility.
🔹 Key Features
Battery-Free Passive Design: Harvests energy from RFID readers; zero maintenance, long lifespan.
Ultra-Thin & Flexible: 0.13–0.2mm thickness, bendable, conforms to curves/irregular surfaces.
High-Temperature Resistance: Withstands -40°C to +85°C (up to 200°C for short periods); compatible with silicone/plastic encapsulation.
Dual Frequency Options:
HF/NFC: 13.56MHz, ISO 14443A/15693 (NTAG213, MIFARE, FM11RF08).
UHF: 860–960MHz, EPC C1 Gen2 (Alien H3/H4, Monza 4D/5).
Customizable: Size (Ø5–15mm, 4×7mm–20×50mm), shape, logo printing, adhesive backing, anti-metal coating, and pre-encoding.
Durable: Polyimide substrate resists moisture, chemicals, and mechanical stress; industrial-grade reliability.
🔹 Specifications
| Item | Details |
|---|---|
| Material | Polyimide (FPC) + Copper Antenna |
| Thickness | 0.13mm / 0.15mm / 0.2mm |
| Frequency | HF (13.56MHz) / UHF (860–960MHz) |
| Protocol | ISO 14443A / ISO 15693 / EPC C1 Gen2 |
| Chip Options | NTAG213, MIFARE Classic, FM11RF08, Alien H3, Monza 5 |
| Read Distance | HF: 1–3cm; UHF: 1–5m (depends on reader/environment) |
| Operating Temp | -40°C to +85°C |
| Storage Temp | -55°C to +125°C |
| Size | Custom (Ø5/6/8/9/10/15mm, 5×5mm, 8×14mm, etc.) |
| Adhesive | 3M adhesive backing (optional) |
| Encoding | Custom UID/EPC encoding (128-bit/256-bit) |
🔹 Applications
Asset Tracking: Small tools, PCB boards, medical devices, lab equipment.
Brand Authentication: Luxury goods, cosmetics, electronics anti-counterfeiting.
Smart Wearables: NFC wristbands, fitness trackers, wearable sensors.
Industrial IoT: Curved-surface tags, high-temperature process monitoring.
Access Control: Miniature NFC tags for door locks, cabinets, and IoT devices.
🔹 Custom Service
We offer one-stop OEM/ODM solutions: custom size/shape, anti-metal layer, adhesive backing, and pre-encoding (UID/EPC).
MOQ: 500pcs;
Lead time: 7–15 days.
Products Feature & Details
Factory & Company View
FAQ
1. What is the difference between FPC RFID tags and ordinary PVC/PET tags?
FPC tags use polyimide (PI) substrate, which is thinner (0.13mm vs 0.5mm), more flexible, heat-resistant (-40°C to +85°C), and durable for harsh environments. PVC/PET tags are thicker, stiff, and not suitable for high-temperature or curved surfaces.
2. Are FPC tags waterproof?
Yes. The polyimide substrate and encapsulated antenna are moisture-resistant and waterproof, suitable for indoor/outdoor and humid environments.
3. Can I use FPC tags on metal surfaces?
Standard FPC tags work best on non-metal surfaces. We offer anti-metal FPC tags with a protective layer to reduce signal interference, enabling stable performance on metal.
4. What is the read distance?
HF/NFC: 1–3cm (standard NFC phone/reader). UHF: 1–5m (depends on reader power, antenna, and environment).
5. Can you encode the tags with custom data?
Yes. We provide pre-encoding service: program unique UID, EPC, or user data (128-bit/256-bit) before shipping.
6. What is the MOQ and lead time?
MOQ: 500pcs; lead time: 7–15 days (depends on quantity and customization).
7. Are samples available?
Yes. We offer free samples (5–10pcs); buyer covers shipping cost. Contact us to request a sample kit.
